Roof Top Cargo Boxes Buying Guide
Choose a roof cargo box by length, not volume
A roof top cargo box is a hard, enclosed shell that mounts to your crossbars, so luggage, skis and camping gear ride on the roof instead of in the cabin. The box you need is decided by its length, not by its volume. Two boxes can hold the same 18 cubic feet and differ by 13": the Inno Phantom is 78.75" long and the Thule Motion 3 XXL Low is 91.7".
Length decides two things. It sets the longest ski or board the box will take, and it sets how far the box reaches behind your rear crossbar, which is where a rear hatch swings up. Height, the side it opens from and how it mounts decide the rest.
Every box here mounts to crossbars, so those come first. If your roof has none, start with roof racks and crossbars and we will fit both. For a box chosen mainly for skis, see ski and snowboard cargo boxes.
Cargo box lengths compared
| Length | Examples | Longest skis | Check before ordering |
|---|---|---|---|
| Short, under 56" | Inno BRL160MBK (44.5", 6 cubic feet); Inno Ridge (55.1", 8 cubic feet) | Not made for skis (the Ridge is 50.4" inside) | Both open on one side only; the BRL160MBK needs an Inno Quick Base (sold separately) |
| Mid-length, 69" to 79" | Thule Pulse 2 M (69", 14 cubic feet); Yakima SkyBox NX LG (75.5", 16 cubic feet); Inno Phantom (78.75", 18 cubic feet) | 155 cm (Pulse 2 M) to 185 cm (Phantom) | The least overhang behind the rear bar; check it takes your longest skis |
| Long, 80" to 85" | Inno Wedge 660 (80", 11 cubic feet); Yakima SkyBox NX XL (84", 18 cubic feet); Thule Motion 3 XL (85.1", 18 cubic feet) | 180 cm (Wedge 660) to 200 cm (Motion 3 XL) | Hatch clearance and crossbar spread (24" to 40" on the SkyBox NX XL) |
| Extra long, about 91" | Thule Force 3 XXL (91.4", 21 cubic feet); Thule Motion 3 XXL Low (91.7", 18 cubic feet) | 215 cm | Overhang at both ends, and the box's own 56 to 57 pounds counts against your roof rating |
Height, opening and mounting
A low box clears a garage door or a parking structure more easily and costs volume: the Thule Motion 3 XL Low is 14" tall and holds 14 cubic feet; the Motion 3 XL is 16.9" tall and holds 18, at almost the same 85" length. Width trades the same way. The Thule Force 3 L Sport, 24.7" wide, leaves more of the bar free for a second carrier; the Inno BRM855BK, 38.5" wide, holds 17 cubic feet and leaves little room beside it.
Most boxes open from both sides, so you can load from the curb whichever way you park. A few Inno boxes open on one side: the Ridge (passenger side only), the BRM720 and the BRL160MBK. The Kuat Varial is hinged at the front and opens on both sides and the back.
Most boxes clamp to round, square, aero and factory crossbars with the hardware in the box; check the bar shapes each one lists (the Inno Ridge does not list aero bars). The Inno BRL160MBK and BRL310MBK lock onto an Inno Quick Base (sold separately) instead of clamping to the bars.
Measure before you order
The common mistake is choosing the box for the skis and finding it stops the hatch. The longest box reaches furthest back, and on an SUV or wagon the open hatch can strike it. Measure three things: the crossbar spread (the distance between your bars), your roof height with the rack on and the distance from the rear crossbar back to the top of the hatch opening. Each box accepts a range of spread (24" to 36" on the Yakima SkyBox NX LG), and the SkyBox NX LG and XL come with a hatch clearance chart.
Then add up the weight. The box, the crossbars and your vehicle's roof each carry a rating, and the lowest one counts. The roof rating covers the crossbars, the box and the load together.
Some boxes, including the Yakima boxes and the Kuat Varial, are sold for in-store pickup only; the product page says which. Call 1-800-272-5362 with the year and model, your crossbars and the longest thing you will carry, and a Rack Specialist will confirm the box, the spread and the hatch clearance on your vehicle.
Common questions
What is the best roof cargo box?
The one that takes your longest skis and still clears your rear hatch on your crossbar spread. After that, choose a low box if garage height matters and a dual-side box if you load from the curb. Every box here mounts to crossbars, so the bars come first.
Do I need a roof rack for a cargo box?
Yes. A cargo box mounts to crossbars, not to the roof itself. If your roof is bare, or has rails with no bars across them, start with roof racks and crossbars and we will fit the bars and the box together.
What size roof cargo box do I need?
Pick the length first: boxes of 69" to 79" take skis of 155 to 185 cm and reach least far over the hatch; boxes of about 91" take 215 cm. Volume is sold in cubic feet, about 28.3 liters each: 14 cubic feet is about 400 liters, 18 about 510 and 21 about 595.
Will a cargo box hit my rear hatch?
It can, depending on the box length, your crossbar spread and where the box sits on the bars. Setting it further forward helps, as far as the front of the roof allows. The SkyBox NX LG and XL come with a hatch clearance chart; for any box, a Rack Specialist at 1-800-272-5362 will check it against your vehicle.
How much weight can a roof cargo box hold?
The Thule boxes and the Kuat Varial are rated 165 pounds and the Inno Wedge Plus 110, but the real limit is your vehicle's roof rating, which covers the crossbars, the box and its contents together. Check the owner's manual, and subtract the box itself: 34 to 57 pounds for the Thule Force 3 boxes.
