Truck Ladder Racks Buying Guide
Start with what your bed gives the rack to hold
An over-bed ladder rack is a set of uprights standing on the truck with a crossbar across each pair, and the part that decides the fit is where those uprights meet the truck. So the rack is decided by what your bed gives it to hold, not by the name on the crossbar. The racks on this page mount five ways: they clamp to the bed rail, bolt through the bed (drilling required), fasten into the stake pockets, slide into a factory bed track or bolt to the top of a service body. The table below compares them, and non-drilling racks, drilled racks and service body racks each have their own page.
On a pickup bed the choice is between clamping and drilling, unless the truck has stake pockets or factory tracks to use. A clamp-on rack grips the top and underside of the bed rail and leaves no holes, but it needs open access under the rail, and on the Thule TracRac clamp-on racks an over-rail bed liner has to come out first; a drilled rack puts permanent holes in the bed, and in return a rack like the System One Contractor Rig bolts its base tracks to the inside lip of the rail, which spreads the load along it. Drilling is not what sets capacity, though. The Thule TracRac Pro 2 clamps on and is rated 1,000 pounds; the Thule TracRac Contractor Steel bolts to the bed sides and is rated 250.
The truck that catches people out is the Toyota Tacoma. From 2005 on, its bed has a built-in track system under the rail, and neither the Vantech P3000 clamp-on nor the WeatherGuard TR801-A fits a Tacoma. The Thule TracRac Pro 2 comes in Tacoma sizes for 2005 through 2015 and for 2016 and newer, and the TracOne fits a 2005 through 2015 Tacoma with the Thule TracRac 34000 mount kit (sold separately, under truck rack accessories), which fastens to the bed's own tie-down track with no drilling.
Compare the ways a rack mounts
| Mount | How it attaches | Drilling | What your truck needs | Ratings on this page |
|---|---|---|---|---|
| Bed rail clamp | Clamps grip the top and underside of each bed rail | None | Open access under the rail; an over-rail bed liner removed for Thule TracRac racks | 800 to 1,000 pounds |
| Bolt-on | Base tracks or brackets bolt to the inside lip of the rail or to the bed sides | Required | A bed you are willing to drill (the Vantech P3000 bolt-on does not fit composite beds such as the 2005 and newer Tacoma or the Ridgeline) | 250 to 1,250 pounds |
| Stake pockets | Base rails fasten into the stake pockets and the uprights slide along them (Thule TracRac SR) | We confirm it for your truck | Stake pockets, base rails cut to your bed length and overheads sized to your cab height | 1,250 pounds |
| Vehicle-specific (RamBox and Ridgeline) | Vantech racks built for one truck: the RamBox rack slides into the factory bed tracks; the Ridgeline racks mount at the plastic bed rail covers | None on RamBox or a 2016 and older Ridgeline; required on a 2017 and newer Ridgeline | On RamBox, the factory bed tracks and no tonneau cover or tonneau cover tracks | 150 pounds on RamBox (light-duty, not recommended for utility use); 600 on Ridgeline |
| Service body | The rack or its base tracks bolt to the top of the body | Bolted to the body top | A body top with room for the tracks (System One racks do not fit flip-top service bodies) and the height from the body top to the cab roof | 600 to 1,250 pounds |
Measure the cab and the bed before you order
Two measurements finish the fit. The first is cab height, because whatever runs forward over the cab has to clear its roof, and the uprights set how high the crossbars sit. They are sized for it: the Thule TracRac Pro 2 stands 25.5" on compact trucks, 27.25" on full-size trucks and 29" on Super Duty and Ram, and the Vantech P3000 adjusts from 21.25" to 28.25", measured from the top of the bed rail to the top of the crossbar. The TracOne has limited clearance on a Ford Super Duty or a Ram Classic, where a load extending over the cab can touch the roof. A rack that fits the bed and not the cab is still the wrong rack.
The second is length. Rails and tracks are cut to it: the TracRac SR base rails are made for your bed length and the System One Contractor Rig parts list is matched to your cab and bed. System One service body racks come in 8', 9' and 11' lengths. On a service body, also measure from the top of the body to the top of the cab roof; we ask for that figure when you order, because it sets the height of the overheads.
Call 1-800-272-5362 with the year and model, the bed length and whether your load rides over the cab, and a Rack Specialist will confirm the mount, the upright height and the hardware your bed needs.
Common questions
What is the best ladder rack for a truck?
The one that mounts to what your bed offers and is rated for what you carry. On this page the clamp-on racks are rated 800 to 1,000 pounds and the System One Contractor Rig and Thule TracRac SR 1,250. The WeatherGuard 1175-52-02, for Super Duty, Ram 2500 and 3500 and Chevy and GMC HD trucks, is rated 1,700.
Can I put a ladder rack on my truck without drilling?
Yes, if the bed gives the rack something to hold. Clamp-on racks grip the bed rail and need open access under it; the Thule TracRac clamp-on racks also need any over-rail bed liner removed. The Vantech RamBox and 2016 and older Ridgeline racks use the truck's own tracks or slots. They are under non-drilling racks.
Which ladder racks fit a service body or utility truck?
Racks built for the body top, not the bed rail. The System One Contractor Rig and Utility Rig service body racks bolt to the body top in 8', 9' and 11' lengths (not for flip-top bodies), and the Thule TracRac service body rack slides on four base tracks bolted to its corners. See service body racks.
Will a ladder rack work with a tonneau cover?
Only when the rack and the cover can share the bed, which we check cover by cover. Some pairings are ruled out: the Vantech RamBox racks do not work with aftermarket or RamBox tonneau covers. Call 1-800-272-5362 with the cover's make and model and a Rack Specialist will tell you which racks clear it.
What ladder rack fits a small truck?
One sized for it. The Vantech P3000 comes with 65" crossbars for mid-size trucks and 72" for full-size, and the Thule TracRac Pro 2 comes in compact and Toyota Tacoma sizes. On a 2005 or newer Tacoma, neither Vantech P3000 nor the WeatherGuard TR801-A fits. Enter your truck in the fit guide and we will show only what fits.
Can I take a ladder rack off my truck when I do not need it?
Yes, and some racks clear the bed without coming off. A clamp-on rack such as the Thule TracRac TracOne comes off with its clamps and leaves no holes. The TracRac SR uprights slide forward along their base rails, and the System One Contractor Rig and WeatherGuard 1175-52-02 let you take out only the rear crossbar for loading.
